hi and welcome on the youtube channel FLOEB , i'm happy to meet you for a new review
the DRS-LC pedals of DEM racing simulators
thank you at DEM for the stickers! one large and 2 small
and one t-shirt of DEM! thank you very much
i present you the pedals in detail, let's go!!
here in detail, the pedals of DEM
an aluminum support of 3mm thickness, it measures 38cm wide and 45cm long
the pedals have a height of 28cm
and the pedals have a length of 26cm
the pedal set weights 10,7kgs , a heavy and quality product
for the throttle, there is a metal structure of 4mm thickness with cylindrical spacers, as the brake and the clutch
all the base of the pedal is in métal , very resistant
for the throttle pad , iron métal manufacture, laser-cut, of 4mm thickness , 15,5cm high, 5,5cm wide
a beautiful design, curved on the top and bottom
and there is a very good grip
the pad will be adjustable in depth, inclination and height
in depth, i could adjust from à to 5cm
in height, i have a possible adjustment of 3cm, so the pedal goes from 28 to 25cm high
there is a bike damper on the throttle pedal
but the spring has been modified for a better feel
and we can adjust the hardness of the pedal with the ring on the damper body, we can adjust on 3 cm, very good
a linear potentiometer on the throttle and the clutch , the potentiometers of high-quality, and high precision
on the bottom, there is a large screw, which will serve as stop for the max position of the pedal
on the bottom, there is a heel support , in iron métal of 10,5cm wire and 4cm high
we can adjust the support with the 4 screws on the pedal, it will require a wrench of 10 .
we can adjust from 0 to 6cm
there is a screw on the bottom for adjust the pedal with the linear potentiometer
on the video, we can see that the adjustment is very precise, to the millimeter
very good
for the brake pedal, the body is in iron métal as the throttle,
the pedal brake works with a load cell of 100kgs of max pressure
we see that there is a rubber pad, with a return spring
1 cm of travel
we can adjust the travel with the bolt and the piece in abs
if i set at least, there is a dead zone on the pedal,and i'm not fan, i prefer to set it without dead zone , to millimeter
for the pad of brake ,it measures 12cm high and 8cm wire, curved on top and bottom
we can adjust the height, depth and inclination
the heel support on the bottom
for the clutch pedal, métal studios 4mm thickness as the brake and throttle
a damper bike
the spring is different from the throttle
for a different feeling
i could also adjust the hardness of the pedal with the ring on the body of the damper and we can adjust on 3cm
a linear potentiometer as the throttle
stop for max pedal pressure
the pad is the same as the brake
4mm thickness , 12cm high and 8cm wire
we can also adjust the height, inclination and depth,
and on the bottom , the heel support
DEM use an electronic card for the pedal set
the electronic card is in the white box
the cars is the Léo Bodnar BU0836-LC 12bit resolution
high quality card
and we connect the USB cable in the back of the box,
the pedal set is delivered with a USB cable
for a pedal set (3 pedals) the price is Eur890 + VAT + shipping
and a pedal set for the fans of formula 1(2 pedals)
the price is Eur690 + VAT + shipping
the aluminum support is in option, the price is Eur6O
the pedal set will be available in different colors( white, yellow,red and black)
i install the pedals on my rig and i test it
i finished the installation of the pedals of DEM racing simulators, i leave on racing with the AUDI90 on the lime rock park track
i do a few laps and a make a conclusion, let's go!
i leave in sequential shifter
i installed the pedal in about 1 hour
and 30mn for the adjustments
the adjustments for the pads and feeling of the clutch and the throttle
many adjustments for this pedal set
depth, inclination, height
very good
i do not need to raise my feet
i just adjust the pads in height
good positive point
i regulated the heels supports , adjustable to the millimeter
very well designed
very good pad for the throttle
15,5cm high , the foot is well resting on it
with a good grip
i also adjust the feel of the throttle pedal
a flexible feeling
we regulates to the millimeter
the brake is excellent
a flexible effect at the beginning which hardens on the end
pedal stroke is short ,about 2cm
i like
a very large pad of 8cm
the foot is well supported on the pedal
i also set the brake pedal for the " hell-and-toe"
a pedal set with multiple adjustments
very good
with a very nice finish
the linear potentiometer works well on the throttle
it's precise
the pedal set will be "plug and play"
just connect it to the pc
and configure it in game
for the clutch , i regulated the feeling
i regulated harder than the throttle
very good feeling with a linear pedal
very well effect in the clutch
the same pad than the brake , 8cm wide
the heel supports are well, the foot rests well on
the last lap
very good pedal set, it is quality, good feeling
the aluminum support of the pedal will be optionnnal, the price is of Eur60,
it is the choice of each, depending on its configuration and rig
this test is finished ,very good feeling, excellent
the positive points are :
- multiple pad adjustment
- the hardness adjustment of the clutch and throttle, it is set to the millimeter, very good
- a USB Léo Bodnar controller, quality materials for this pedal set
and the negative points are :
the impasto of the pedal set, it will require a good rig
the tightening of the bolts, it will be necessary 2 wrench, it is not simple
i thank DEM for the sending of the pedal and to give me confidence to realize the review
i would put the link in the description of the video to acquire this pedal set
and now you have 5% discount with the "FLOEB" code on the website of DEM for the purchase of a pedal set (expiration date april 30)
like my Facebook page
subscribe to my youtube channel
like and comment
and i give you appointments for a next review ! BYE !!!
